52 Series Ball valve

52 Series Ball valve

Sanitary Ball valve is used process piping system for either isolation or diversion of the fluid, manually or automatically operated.

A ball valve is constructed with a full bore or full port design with zero flow restriction making it an viscous or particulate liquid.

Cipriani Harrison Ball valves are available with different version to suite its respective application.

The full bore design compliments effective cleaning and can also make it suitable to be used for product recovery system handling wide range of product viscosity.

DESIGN

• Cipriani Harrison Ball valve is made up of forged precision machined ball with a full port, assembled inside a valve body with two flanges.
• Cipriani Harrison 52-Series Ball valve is made from forged raw material.
• This ball valve has a three piece construction consisting of a body and the two flanges.
• The ball is precisely located inside the body, which can be either cavity filled or give with purge ports.

SEAL

Cipriani Harrsion’s Ball Valve are available with comprehensive range of seal option, to fit in the required environment.

Different options of seals are available to suite different thermal environment and chemical resistance, intern increasing the seal life.

Cipriani Harrison has a special designed PTFE seal, to suite more aggressive media.
