Number of stirring positions
|
1
|
|
Stirring quantity max. per stirring position (H2O)
|
20 l
|
|
Motor rating output
|
9 W
|
|
Direction of rotation
|
right / left
|
|
Speed display set-value
|
LCD
|
|
Speed display actual-value
|
LCD
|
|
Speed adjustment
|
Turning knob
|
|
Speed range
|
50 - 1500 rpm
|
|
Setting accuracy speed
|
10 rpm
|
|
Stirring bar length
|
30 - 80 mm
|
|
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h)
|
+13 K
|
|
Heat output
|
850 W
|
|
Temperature display set-value
|
LCD
|
|
Temperature display actual-value
|
LCD
|
|
Temperature unit
|
°C / °F
|
|
Heating temperature range
|
Room temp. + device self heating - 310 °C
|
|
Heat control
|
Turning knob
|
|
Temperature setting range
|
0 - 310 °C
|
|
Temperature setting resolution of heating plate
|
1 K
|
|
Connection for ext. temperature sensor
|
PT1000, ETS-D5, ETS-D6
|
|
Temperature setting resolution of medium
|
1 K
|
|
Adjustable safety circuit
|
50 - 370 °C
|
|
Set-up plate material
|
Aluminum with ceramic coating
|
|
Set-up plate dimensions
|
137 x 137 mm
|
|
Automatic reverse rotation
|
yes
|
|
Intermittent mode
|
yes
|
|
Viscosity trend measurement
|
yes
|
|
Timer
|
yes
|
|
Timer display
|
LCD
|
|
Time setting min.
|
1 s
|
|
Time setting max.
|
143940 min
|
|
Sensor in medium detection (Error 5)
|
yes
|
|
Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C)
|
±2 %
|
|
Heating rate (1l H2O in H1500)
|
7.5 K/min
|
|
Heat control accuracy of heating plate (at 100°C)
|
±5 K
|
|
Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C)
|
±0.5 K
|
|
Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C)
|
±0.5 K
|
|
Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C)
|
±0.2 K
|
|
Dimensions (W x H x D)
|
160 x 85 x 270 mm
|
|
Weight
|
2.6 kg
|
|
Permissible ambient temperature
|
5 - 40 °C
|
|
Permissible relative humidity
|
80%
|
|
Protection class according to DIN EN 60529
|
IP 42
|
|
RS 232 interface
|
yes
|
|
USB interface
|
yes
|
|
Voltage
|
220 - 230 V
|
|
Frequency
|
50/60 Hz
|
|
Power input
|
900 W
|
|
Power input standby
|
1.6 W
|
