Natoli Engineering

MANUAL 3-IN-1STAINLESS STEEL TABLET HARDNESS AND THICKNESS TESTER

An economical, simple-to-use machine that accurately calculates the hardness, thickness diameter, and length of solid dosage forms.

Features:

• Touch screen display
• Capable of up to 250 samples per test
• Electronic load-cell
• Adjustable break between samples
• Constant force and constant speed measuring principles available as standard
• Programmable calibration and verification modes
• Auto/Manual mode with programmable time delay
• Printing (serial/ethernet) for data and graph selectable – RS232 Serial

Specifications:
Range: 10-500N
Accuracy: ± 1N
Diameter/Thickness: ± 0.02 mm
Hardness: ± 1N
Units: N, Kp, Sc
