Colamark Technologies Limited

V120 Vision Tablet Counter

Colamark V120 vision tablet counter is an innovative revolutionary counting solution for tablets and other discrete products. Protected by various patents, V120 employs high speed imaging technology, bulk counting method, and an innovative aggregation algorithm that offers 5 major advantages:- (a) long camera distance from materials - minimum dust contamination; (b)bulk counting - fast and precise; (c) Logical allocation method - no high speed shutter needed; (d) integrated channels - no multiple layer vibrating platform needed for maximum foot print efficiency; (e) high resolution - allows detecting broken tablets and debris effectively, and rejection in small batches.

A vision counting and aggregation method that is revolutionary from the traditional multiple channel counting method. The material flow is conveyed by a vibrating plate in a single layer manner, and is counted in batches precisely while falling down from the vibrating plate by a high speed camera. There is no need to divide the material flow into single channels like in the traditional multiple channel method.

The first generation of vision based counter uses a difference compensation method whereby tablets are supplied and counted in bulk up to a quantity close to the target first, then a secondary dispenser dispenses exactly the difference from the target into the first batch to achieve the target quantity. This method requires the secondary dispenser to align the tablets in single channels in order to control the quantity dispensed at single pieces. This is actually similar to the process of the tradition multi-channel method and therefore is still subject to the inherited constraints of it.
