Shell & Tube Heat Exchangers-Safety

SAFETY HEAT EXCHANGERS

When safety is your number one priority

The range of safety shell-and-tube heat exchangers is based on the “three chamber devices” principle, which was developedand patented by the company’s founder Karl-Heinz Funke.

OPERATING PRINCIPLE OF A SAFETY HEAT EXCHANGER

Here with double tubes, double sheets and leak sealing liquid

DESIGN FEATURES

• Media separated by double tube bundles, media cannot mix
• Special sealing liquid for immediate leak indication
• Leakage system works independently of the installation position
• Leakage detection is possible through process control
• Suitable for a wide range of liquid media

APPLICATION

Safety heat exchangers are used wherever the highest requirements for product purity in process engineering (e.g., food/pharmaceutical industry) are required, where there is an environmental risk of contaminating cooling or process water, or because mixing of the media can damage the machine or system.
