GEMU 417 Manually operated butterfly valve

GEMU 417 Manually operated butterfly valve

Description

The GEMÜ 417 butterfly valve has an ergonomically designed corrosion resistant plastic hand lever. It can be protected against accidental operation by the integrated locking device.

Features

• Low weight
• Corrosion resistant plastic body
• Simple installation with union nut
• Ergonomic handle with anti-twist system and locking device

Technical specifications

• Media temperature :0 to 60 °C
• Ambient temperature:-10 to 60 °C
• Operating pressure :0 to 6 bar
• Nominal sizes:DN 15 to 50
• Connection types:Union end
• Connection standards:BS | DIN
• Housing materials:PVC-U, grey
• Liner materials:EPDM | FKM
• Disc materials:PVDF
• Conformities:EAC
