Wet Glue Labeling Machine Model PAWGBL-120

Wet Glue Labeling Machine Model PAWGBL-120

DESCRIPTION:

The Wet Glue Labeling Machine Model PAWGBL-120 is one of the most users friendly. The machine is used for full/partial labeling on different size of Flat, square, round or rectangular bottle or other containers. Wet Glue Labeller is capable of labeling up to 120 containers per minutes depending on products and label size. The automatic model is equipped with roller spacing device resulting in a simple operation with “No change parts required”. The round bottle labelling machine has the working direction from left to right. The output of the machine is up to 200 bottles per minute.

A maximum label length can be applied by the round bottle labeling machine by maintaining a space of 3mm between the labels. On the other hand, square bottle labelling machine boasts of the presence of imported sensor from Germany. The labeling machine has a high production speed with accurate label placement. There is a provision for product data storage as well in the round and square bottle labelling machine.

WET GLUE LABELING MACHINE OPERATION:

The filled and sealed or Empty bottle received from the Turn Table is conveyed from the Conveyor and on the same conveyor one bottle separator attachment is provide to separate the bottle from continuous movement also two pressing device is provided .on conveyor to straight the bottle & after straight position top holding pressing device is pickup the bottle in original position after pick up the bottle by top pressing device side pressing device release bottle during releasing portion a sensor provided to sense the product after sensing the sensor give command to operate steeper or servo motor to release label when one label is stick the gap sensor give command to stop the servo or stepper during releasing of label provision of brush to press the label & remove the air between label & bottle after completion of the cycle one operation of labelling is finish & conveyor bring the bottle for next operation.

SALIENT FEATURES:

• High Production Speeds.
• Mild steel structure cladded with stainless steel 304 sheet to meet GMP norms.
• Accurate label placement.
• Product data storage facility.
• No change parts requirements.
• Very less down time for change over.
• Suitable for Glass, Plastic, Pet, Tin, Corrugated containers.

OPTIONAL FEATURES: WET GLUE LABELLER

• Round bottle labeling attachment. ( combo Flat and Round Bottle Labeling Machine)
• Label Roll Empty – Machine Stop System with Alarm
• Option of Contact Coder, Hot Foil Coder, HP Cartridge Coder and Inkjet Coder with various speed ranges available.
• Tower Light showing the machine status / operation
• Colour or Mono Touch Screen with PLC for machine operation and showing various error messages and information on display
• Vision System for checking Barcode, presence or absence of Coding or pharma code on labels
• Vision System with OCR system for checking coding on labels
• Online pneumatically operated product rejection system

UTILITY REQUIREMENT: BOTTLE LABELLING MACHINE
