Tablet Press CTX

Tablet Press CTX

The Cadmach CTX is a high speed Single Rotary Tablet Press built on the latest principles of tablet machine technology. A unique 3 Pillar Design CTX is a versatile and economical tablet press for High batch production. The machine primarily offers simplicity of operation, operator safety and ease of maintenance. The CTX Tablet Press is offered in 26D, 32B & 40BB Turret Configurations.

Important Specifications:

Dial present in Front for Tablet Parameters Controls
Pre-Compression available of 10kN & Main Compression of 100 kN
Uniquely designed Oil Immersed Central Drive Gearbox by CADMACH
Compaction Force Control (CFC) system for Auto Weight Control with 15” Touch-screen Computer Panel for SCADA
Single Tablet Rejection even at highest speed of operation
3 Pillar design concept makes the machine sturdy, compact, light -weight and mobile, which is the need of the pharmaceutical Industry
Zero Clearance Force Feeding System

TECHNICAL SPECIFICATION

MACHINE TYPE	CTX-26	CTX-32	CTX-40
No. of station	26	32	40
Type of tooling	D	B	BB
Rated output (tablets / hour)*	18,700 to 109,200	23,000 to 134,400	28,800 to 168,000
Max. Compaction force-Main (kN)	100	65	65
Max. Compaction force-Pre (kN)	10
Max. Tablet diameter (mm)	25	16	13
Max. Depth of die fill (mm)	20	16	16
Max. Tablet thickness (mm)	8.5
Upper punch penetration-Main comp. (mm)	3 to 6
Main ele. motor (kW / hp)	3.7 / 5.0
Power consumption (kW / hp)	4.9 / 6.5
Power supply	220 / 380 / 415 / 480 V +10%, 3 Ph., 50 / 60 Hz
Overall dimensions (cm)	100 W x 141 D x 198 H
Net weight (kg)	1450
