External Dimensions:
Length (2 port): Length (3 port): Length (4 port):
Depth: Height:
1820mm 2220mm 2620mm
750mm 1080mm
Internal Dimensions:
Depth: Height front: Height rear:
1094mm 1494mm 1894mm
669mm 300mm 894mm
Weight:
2 port: 3 port: 4 port:
240Kg 265Kg 290Kg
Volume:
0.59m³ 0.81m³ 1.03m³
Leak Rate:
0.05% of volume of box per hour @ /- 4” WG
Material:
Stainless steel Type 304
Finish:
Satin non glare
Electrical: Internal sockets: Lighting:
One twin Fluorescent (external)
Controls:
Intuitive touch screen control
Meters: Oxygen meter: Moisture meter:
Digital, PLC controlled, range: % or PPM
Lockchambers: Number: Large internal dimensions: Small internal dimensions: Construction: Material: Finish: Internal External Doors:
Door operation: Internal External Internal External
Purging: Pressure gauge:
Two Ø300mm x 550mm long Ø125mm x 300mm long Cylindrical Stainless steel (304), thickness 3mm Satin non glare Satin non glare Anodised aluminium, 12mm thick, one hand operation Small: Lift off Lift off Large: Counterbalanced upward lift Hinged
Manually operated valves Analogue
Pressure Control:
Full automatic pressure control via PLC controller
Over/under pressure is maintained by a low maintenance gas bubbler -2000 to 500 Pa (-8 to 2 WG)
Gas Scrubbing System:
Closed loop re-circulation system Automatic via PLC controller
Attainable Purity: < 1ppm moisture < 1ppm oxygen
Blower: Precision side channel blower Quiet running High flow rate Long life Oil free Internally mounted
Regeneration: Off box regeneration system sequence
Window:
Toughened safety glass 10mm
Glove Ports:
Anodised aluminium
Gloves:
8” (204mm diameter) Individually gas purgeable Glove change independent of external atmosphere
Shelves:
Two adjustable, stainless steel
Options:
Vacuum pump: Cold wells: Stand:
Switchable positive/negative control Polycarbonate window Gas/electrical/signal breakthroughs Fully radiused corners for nuclear
work 316 stainless steel construction Polycarbonate/acrylic construction
Single or double sided configuration
Edwards (RV5 recommended) To customer’s specification Powder coated mild steel (stainless steel option) including fixed feet or castors
To customer’s specification
Custom design model
