Gravity Convection Oven
Gravity Convection Ovens are especially designed to best handle light weight materials such as powder, fabrics, films and granular materials etc. As these types of materials require natural air flow, these gravity convection oven units do not have fan or blower fitted inside the chamber. The role of these ovens also becomes more important, where testing two or more samples at same time is necessary and avoiding cross contamination between samples is prime requisite.
We make several types of gravity ovens to meet budget limitations and application needs of our customers. Economical models are designed with Powder-Coated Cold-Rolled Steel exterior and aluminum interior and rotary switch for temperature adjustment; while, premium range features stainless steel exterior and interior both and microprocessor controlled temperature and time adjustment device. Each unit offers highly efficient heating. With low watt density heating elements, these units keep your energy consumption low.
Features:
Ideal for powder testing
Available at economical price range
Over temperature protection
Superior temperature accuracy
Intake/exhaust vents
Rugged construction
Low watt density heating element
Double wall insulation
Gravity Oven Dimensions
Model No.
Inner Chamber
(W x D x H)
Volume
(Liters)
Load
(KW)
Shelves
(No’s)
BST/GCO-1122
300 x 300 x 300 mm
30
1.5
2
BST/GCO-1123
355 x 355 x 355 mm
45
BST/GCO-1124
455 x 455 x 455 mm
95
2.0
BST/GCO-1125
455 x 455 x 605 mm
125
2.2
3
BST/GCO-1126
605 x 605 x 605 mm
224
2.5
BST/GCO-1127
605 x 455 x 910 mm
252
BST/GCO-1128
605 x 605 x 910 mm
336
3.0
Gravity Convection Oven Specifications
Temperature Range
Ambient +5°C to 250°C
Temperature Accuracy
+ / - 2°C
Temperature Uniformity
+ / - 1°C
Controls
PID Controller
Temp Display
LED Display
Sensor
PT-100
Heating Element
Nichrome wire / Kanthal A1
Safety device
- Over temperature protection
- Electric leakage breaker
Chamber MOC
Exterior: MS powder coated
Interior: 304 stainless steel
Insulation
Mineral Wool
Doors
Solid doors w/ silicone rubber gasket & lock
2 – 3 Nickel-chrome plated wire shelves (Detachable)
Optional Accessories
- Dot Matrix Printer interface
- Temperature chart recorder
- PLC Controller
- Stainless steel outer cabinet
- Audio / visual alarm
- IQ, OQ, PQ and DQ documentation
- Heating Thermostat
- NABL Certification
- Thermometer
- Stand or wheeled trolleys
Power Supply
220 Volts 50 Hz
